TD1500

Frequency

50Hz

60Hz

Rated Power

1.3kw

1.5kw

Max Power

1.5kw

1.7kw

Voltage (AC)

220V 230V 115/230v

120V? 240V 120V/240V

Engine Speed

3000rpm

3600rpm

DC Output

12V-8.3A

Power Factor

cosφ=1.0

Phase number

Single phase

Start Mode

Recoil

Net Weight

38kg

Dimensions (L×W×H)

605mm×455mm×455mm

Engine Model

TD154F-1

Type

Single cylinder、4-stroke gasoline

Ignition model

Transistor、Zero touch point

Continuous Output

3.1kw/3000rpm

Maximum Output

3.4kw/3000rpm

Bore × Stroke

68mm × 45mm

Compression ratio

8.5:1

Displacement

163cm3

Fuel Tank Capacity

15L

Lube-oil Capacity

0.6L

Crankshaft Direction

Anti-clockwise from flywheel end

Cooling Type

Force air-cooled

Fuel type

Automotive unleaded gasoline

Lube oil brand

CC or CD grade

Fuel type

Automotive unleaded gasoline

Lube oil brand

CC or CD grade
